Bring the power

Fill your whole room with sound. An impressive 300W of total system power puts you in control. Your movies and music have never sounded so good.

Surround yourself with sound

JBL Surround Sound instantly brings movies, sports and music to life. Upgrade to an immersive sound experience for your TV without any extra wires or speakers.

General Specifications

Power supply

100 – 240V AC, ~ 50/60Hz

Operating temperature

0°C – 45°C

Audio Specifications

Total speaker power output (Max. @THD 1%)

300W

Output power (Max. @THD 1%)

2 x 50W (Soundbar), 200W (Subwoofer)

Transducer

4 x race-track driv-ers + 2 x 1” tweeter (Soundbar), 6.5” (Subwoofer)

Soundbar and Subwoofer standby power

<0.5W

Frequency response

40Hz – 20KHz

Audio inputs

1 Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)

Dimensions

Dimensions (W x H x D)

965 x 56 x 85 (mm) / 38” x 2.2” x 3.4” (Soundbar)

Dimensions (W x H x D)

240 x 240 x 379 (mm) / 8.9” x 8.9” x 14.6” (Subwoofer)

Weight

2.14 kg (Soundbar)

Weight

5.61 kg (Subwoofer)

Packaging dimensions (W x H x D)

1045 x 310 x 405mm

Packaging weight (Gross weight)

10.32kg

Control and Connection Specifications

USB port

Type A

USB rating

5V DC/ 0.5A

Supporting file format

mp3, wav

MP3 Codec

MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3

MP3 sampling rate

16KHz – 48 KHz

MP3 bitrate

80kbps – 320kbps

WAV sample rate

16KHz – 48 KHz

WAV bitrate

Up to 3000kbps

Bluetooth version

4.2

Bluetooth profile

A2DP V1.3, AVRCP V1.5

Bluetooth frequency range

2402MHz-2480MHz

Bluetooth Max. transmitting power

<10dBm  (EIRP)

Modulation Type

GFSK, π/4 DQPSK, 8DPSK

5G Wireless frequency range

5736.35 – 5820.35MHz

5G Max. transmitting power

<9dBm (EIRP)

Modulation Type

π/4 DQPSK
